I. Function Introduction

a) Divide the input signal power of the correction source into 7 correction source outputs;

b) Select the signal source for the 7-channel RF output interface according to the control command;

c) Control whether there is a correction source signal output at the 1-channel correction source output interface according to the control command;

d) Output frequency range: 30MHz to 3000MHz;

e) Correction input: 1 channel;

f) Antenna input: 7 channels;

g) Corrected output: 1 channel;

h) RF output: 7 channels.

Ii. Equipment Structure

Equipment size: Customized module cavity;

Net weight of the product: ≤1kg

Iii. Delivery of Materials

Factory inspection report

Product Qualification Certificate

If you would like to know more detailed information about this equipment, please feel free to contact our sales staff.
